全自動生產線：

型號：JOM-D014

功能：送料，沖孔，穿管，漲牙，鉚接全自動一體機

功率: 12.15 Kw

電壓: 380V/50HZ 3相4線

梯子寬度: 350-600mm

梯子間距 :260-300mm

機器尺寸 : 7000x3100x1700mm

機器重量: 3000Kg

Fully Automatic Production Line

Model:JOM-D014

Function:Feeding material ,Punching the holes ,Inserting the tubes, expanding and riveting in one Machine

Cycle Time:25seconds for the punching, inserting, expanding and riveting .

Motor Power: 12.15 Kw

Power: 380V/50HZ Three phase four wire

Process

ladder width: 350-600mm,

Distance of ladder rung:260-300mm

Overall dimensions: 7000x3100x1700mm

Net Weight: 3000Kg

HS CODE:8462411900
